In the fields of automobile manufacturing and repair, the selection of sheet metal materials directly affects the body strength, anti - corrosion performance, and processing efficiency. The following systematically analyzes seven key types of metal sheets commonly used in automotive sheet metal operations from the dimensions of material characteristics, process advantages, and typical application scenarios.



1. Cold - rolled thin steel sheets

Cold - rolled thin steel sheets have high surface finish and excellent dimensional accuracy, making them suitable for body panels with strict flatness requirements, such as car doors and engine hoods. They have low cost and are easy to stamp and form, but are susceptible to environmental corrosion without anti - rust treatment. They often need to be combined with electrophoresis or painting processes to extend their service life.

CNC hydraulic shearing machine

2. Electro - galvanized cold - rolled thin steel sheets

By electro - galvanizing the surface of cold - rolled sheets, this material retains the processing performance of cold - rolled sheets while significantly improving its oxidation resistance. It is suitable for parts with medium anti - rust requirements that need to balance economy, such as in - vehicle brackets and non - exposed structural parts.



3. Hot - dip galvanized thin steel sheets

The dense zinc layer formed by the hot - dip galvanizing process provides excellent anti - rust protection, especially suitable for parts in contact with high - humidity environments, such as automobile chassis and frames. Its coating has strong adhesion and can withstand complex bending and forming, making it one of the core materials for body protection in mid - to high - end vehicles.



4. Aluminum - zinc coated sheets

Combining the weather resistance of aluminum and the sacrificial anode protection characteristics of zinc, aluminum - zinc coated sheets perform excellently in long - term exposure scenarios (such as car roofs and wheel arch linings). Their salt - spray corrosion resistance is more than three times that of ordinary galvanized sheets, and they are often used in vehicle design in regions with harsh climates.



5. Stainless steel sheets

SUS304 stainless steel, with its excellent corrosion resistance and mechanical strength, is mostly used for parts that need to combine functionality and aesthetics, such as exhaust pipes and decorative strips. Its characteristic of not requiring surface treatment can reduce maintenance costs, but it has higher requirements for stamping equipment.



6. Aluminum alloy sheets

Aluminum alloy materials represented by 5052 and 6061 are widely used in lightweight design parts such as inner door panels and engine hoods due to their low density and strong corrosion resistance. Their forming requires special molds, but they can reduce the body weight by 30% - 40%, meeting the weight - reduction requirements of new - energy vehicles.



7. Copper - based sheets (copper/brass)

Copper and brass are often used in special scenarios such as grounding points of vehicle electrical components and wiring harness brackets due to their outstanding electrical conductivity and ductility. Although the cost is relatively high, their repeat - weldable characteristic is irreplaceable in the repair of precision electronic components.



Material Selection Suggestions and Trends

Modern automotive sheet metal materials are evolving towards compounding and lightweighting. For example, the mixed application of high - strength steel and aluminum alloy can balance safety and energy consumption, and nanocoating technology further extends the service life of galvanized materials. In repair scenarios, the material suitability needs to be comprehensively evaluated based on the damage location, repair process, and cost budget. For example, for structural damage, original - equivalent sheets should be preferred, and for non - load - bearing parts, economical alternative solutions can be considered.
