Video demonstration
Suitable for art sculpture, decorative parts, and high-end sheet metal surface forming
Watch VideoVideo demonstration
Product details
|
|
 |
The JIANMENG PMF400 pneumatic forming machine completes impact and forming through pneumatic drive, including curved surface forming, hammer-texture striking, flattening, and pressing operations, effectively preserving material ductility and structural strength.
It is suitable for users with high requirements for detail and surface craftsmanship and is a cold-working equipment tailor-made for the metal art and custom sheet metal industry.
Particularly, it is ideal for diverse applications such as metal sculpture, artistic shaping, craft prototyping, and bodywork and panel repair.
Technical specifications of Universal Pneumatic Forming Machine
| Item | Value | Item | Value |
| Steel (Rm tensile strength = 400 N/mm²） | 5.0 mm | Aluminum (Rm tensile strength = 250 N/mm²） | 6.0 mm |
| Copper (Rm tensile strength = 250 N/mm²） | 6.0 mm | Stainless steel (Rm tensile strength = 600 N/mm²） | 3.0 mm |
| Horizontal throat opening | 400 mm | Vertical throat opening | 500 mm |
| Work schedule | 50 mm | Stroke frequency | 60 - 80 |
| Cylinder thrust | （0.6MPa） 1529 kg | Air supply pressure | 0.5-0.8 MPa |
| Overall dimensions | 790×700×1710 mm | Weight | 350 kg |
Characteristics of Kraftformer Tools
① This machine adopts an open C-shaped structure, with flexible operating space and small footprint, suitable for placement in studios, maintenance workshops, or teaching places.
② Equipment with 8 sets of professional molds: including 6 sets of curved molds with different curvatures, 1 set of hammer pattern decoration molds, and 1 set of flat shaping molds. Mold replacement is simple and fast, which can meet different creative and processing needs, significantly improving process adaptability and production efficiency.
③ The side is equipped with a regulator that can control the size of the airflow.
④ Pneumatic systems have lower noise levels compared to traditional mechanical equipment.
⑤ Foot switch operation, allowing both hands to freely move the workpiece.
⑥ Equipped with a mold protective cover, effectively preventing hand injuries during operation.
Tools of Pneumatic Punch Former
Flat bottom mold and flat mold
Flat bottom mold and flat mold
Flat bottom mold and hammer pattern mold
C-R400mm-and-A-R400mm
C-R300mm-and-A-R300mm
C-R300mm-and-A-R300mm
C-R200mm-and-A-R200mm
C-R200mm-and-A-R200mm
C-R200mm-and-A-R200mm
C-R130mm-and-A-R130mm
C-R70mm and A-R70mm
C-R70mm-and-A-R70mm
Application Field of Automatic Pneumatic Forming Machine Custom Oem
Bronze
Relief sculpture
Metal sculpture
Art deco
Automotive restoration
Aluminum product customization
The Jian Meng pneumatic forming machine is not only suitable for materials such as aluminum, copper, and stainless steel, but also widely used in fields including metal art processing, sculpture creation, automotive body restoration, antique repair, metalcraft education, rail transit maintenance, and architectural decoration. It is particularly ideal for small-batch, highly flexible personalized customization tasks.
FAQ
Product and Industry FAQ
Are you a factory or a trading company?
We are a manufacturer specializing in sheet metal processing equipment with extensive experience.
Where is your company located?
Our company is located in Taixing City, Jiangsu Province, very close to Wuxi Shuofang Airport and Ch
What certifications do your machines have?
We hold numerous invention patents and quality certification documents.
Do you accept OEM customization?
Yes, we accept OEM customization, which includes customizing the appearance, color, configuration
What is your minimum order quantity?
We accept a minimum quantity of one and can customize it via OEM to meet your specific needs.
What is your delivery time?
Normally, we deliver within 30 days. For non-standard customized machines, it may take a bit long
What kind of packaging do you use for your equipment?
Due to the large size of our machines, we usually load them directly into containers and secure t
Do you provide detailed and professional installation manuals?
Absolutely. Along with the machine, we provide various manuals, operation instructions, precautions,
How do you offer after-sales service?
We provide remote assistance from our mechanical engineers to help resolve minor issues during ma
Do you provide training?
Yes, you're welcome to send your staff to our factory for hands-on training, where we offer prof
